Specifications
This section contains the specifications for the AWG70000A series Arbitrary
Waveform Generators and the AWGSYNC01 Synchronization Hub. The
generators a
re covered together in the first part, followed by the separate
AWGSYNC01 information.
All specific
ations are typical unless noted as warranted. Warranted specifications
that are m arked with the
symbol are checked in this manual.
Performance conditions
To meet specifications, the following conditions must be met:
The instr
ument must have been calibrated/adjusted at an ambient temperature
between +20 °C and + 30 °C.
The inst
rument must be operating within the environmental limits. (See
Table1-32onpage1-21.)
The ins
trument must be powered from a source that meets the specifications.
(SeeTable1-30onpage1-18.)
The in
strument must have been operating continuously for at least 20 minutes
within the specified operating temperature range.
AWG70000A Series and AWGSYNC01 Technical Reference 1–1
