Specifications
Electrical sp
ecifications
Table 1-1: Run mode
Characteris
tics
Description
Continuous m
ode
An arbitrary
waveform is output continuously.
Triggered mode
An arbitrar
y waveform is output only once when a trigger signal is applied. After the waveform
is output, the instrument waits for the next trigger signal.
Triggered
continuous mode
An arbitrary waveform is output continuously after a trigger signal is applied.
Table 1-2: Arbitrary waveform
Characteristics Description
Waveform memory
AWG70001A
Standard
2,000,000,000 points
With Option 01 8,000,000,000 points when ≤25 GS/s
16,000,000,000 points when >25 GS/s
AWG70002A
Standard
2,000,000,000 points
With Option 01
8,000,000,000 points
Minimum waveform size
AWG70001A
1 point in continuous run m ode
4800 points in triggered run modes
AWG70002A
1 point in continuous run m ode
2400 points in triggered run modes
Waveform granularity
AWG70001A
1 point in continuous run m ode
2 points in triggered run modes
AWG70002A
1 point in continuous run m ode
1 point in triggered run modes
Waveform interleaving Interleaving is performed without zeroing
AWG70001A Non-interleaved when ≤25 GS/s, interleaved when >25 GS/s
AWG70002A
Non-interleaved at all sample rates
DAC resolution
8-bit, 9-bit, or 10-bit
