Tektronix AWG70001A User Manual

AWGSYNC01
Table 1-34: Pow
er supply
Characteristic Description
Power
Power Supply AC Line Input 100 – 240 VAC, 50 / 60 Hz
Power Consumption
110 W
Safety U.S. Nation
ally Recognized Testing Laboratory (NRTL) Listing UL61010-1 S tandard for Electrical
Measuring and Test Equipment or ANSI/ISA S82.02.01 Safety Standard for Electrical and
Electronic Test, Measuring, Controlling, and Related Equipment
Canadian C
ertification CAN/CSA C 22.2 No. 61010.1 Safety Requirements for Electrical
Equipment for Measurement, Control, and Laboratory Use
European Union Compliance Low Voltage Directive 73/23/EEC EN61010-1 Safety Requirements
for Elect
rical Equipment for Measurement, C ontrol, and Laboratory Use
Additional Compliance IEC61010-1 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use
Mechanical characteristics
Table 1-35: Mechanical characteristics
Charac
teristic
Descri
ption
Dimensions
Main body Height: 1.75"
Width
: 16.80"
Depth: 20.79"
Over
all w ith feet & handles
Height: 1.75"
Widt
h: 18.13"
Depth: 23.76"
Net Weight Instrument: 11.2 l bs
Inst
rument with packaging: 20.0 lbs
Cooling Clearance
Top: 0"
Bottom: 0"
Sid
es: 0"
Rear: 2"
AWG70000A Series and AWGSYNC01 Technical Reference 1–25
