Page #40 background image
AWGSYNC01
Table 1-33: Electrical specications (cont.)
Characteristic Description
Pattern Jump Input
Connector 15-pin DSUB on rear-panel
Pin Assignments
Pin, Signal
1GND
2 Jump Bit 0 Input
3 Jump Bit 1 Input
4 Jump Bit 2 Input
5 Jump Bit 3 Input
6GND
7 Strobe Input
8GND
9GND
10 Jump Bit 4 Input
11 Jump Bit 5 Input
12 Jump Bit 6 Input
13 Jump Bit 7 Input
14 GND
15 GND
Input Impedance
1k pull-up to 5 V
Input Levels
3.3 V LVCMOS, 5 V TTL compliant
Number of Destinations
256
Strobe Polarity
Negative
Strobe Minimum Pulse Width
(typical)
64 ns
Strobe Setup and Hold (typical) Setup: 5 ns
Hold: 5 ns
Latency to Analog Output
(typical)
102,125 / sampling clock +20 ns ± 20 ns
Holdoff Time
>18 μs
Sync Port
Number of ports
4
Function
Proprietary interface for connecting to the AWG SYNC hub. Enables synchronized c locking
and triggering of multiple AWG instruments.
Connector 62-pin Samtec EI8-031-S-D-RA on the rear panel
