Tektronix AWG70001A User Manual

AWGSYNC01
Table 1-33: Electrical specifications (cont.)
Characteristic Description
Input Amplitude (typical)
+5 dBm to +10 dBm
Frequency Range (typical) 6.25 GHz to 12.5 GHz
Sync Clock O utput
Connector SMA on rear-panel
Output Impedance 50 Ω AC coupled
Output Amplitude (typical) 1.0 ±0.15 V
p-p
into 50 Ω
Frequency
Clock Output ÷ 80
Trigger Input
Number of Inputs
2
Slope / Polarity
Positive or negative selectable
Connector SMA on rear-panel
Input Impedance
1kΩ or 50 Ω selectable
Input Voltage R ange When 1 k is selected: –10 V to +10 V
When 50 Ω is selected: <5 V
RMS
Input Minimum Amplitude
(typical)
0.5 V
p-p
Threshold Range –5.0 V to +5.0 V
Threshold Resolution 0.1 V
Threshold A ccuracy (typical) ±5% of setting + 0.1 V
Trigger Minimum Pulse Width
(typical)
When 1 kΩ is selected: 20 ns
When 50 Ω is selected: 20 ns
Trigger Delay to Analog Output
(typical)
Synchronous trigger mode: 30,800 / (2 * sampling clock) + 20 ns ±20 ns
Trigger Asynchronous Jitter
(typical)
80 / sampling clock frequency
Trigger Synchronous Jitter
(typical)
Clock In = 12.5 GHz:
300 fs rms, 4.2 ps R J
p-p
BER@10-12
Variable Reference In = 156.25 MHz:
400 fs rms, 5.6 ps R J
p-p
BER@10-12
Fixed Reference In = 10 MHz:
1.7 ps rms, 23.8 ps RJ
p-p
BER@10-12
Sample rate = 25 GS/s
Trigger input impedance = 50
AWG70000A Series and AWGSYNC01 Technical Reference 1–23
