Performance tests
Table 2-3: Required equipment for performance tests (cont.)
Item Qty. Minim um requirements Recomm ended equipm ent
50 Ω BNC cable
1 ea. Male connectors both ends Tektronix part number 012-0057-01
SMA-BNC adapter
3 ea.
SMA female to BNC male connector
Tektronix part number 015-0572-00
SMA-BNC adapter
1 ea.
SMA male to BNC female connector
Tektronix part number 015-0554-00
BNC-dual banana adapter
1 ea.
BNC to dual banana plugs
Tektronix part number 103-0090-00
Test waveforms
The following table lists the test waveforms that are used for the performance
verifica
tion procedures. These are included on the instrument hard drive at:
C:\Program Files\Tektronix\AWG70000\Samples\PV.
Table 2-4: Performance test waveforms
Waveform name Purpose
PV_DC_Minus.wfmx
PV_DC_Plus.wfmx
For checking the analog amplitude accuracy and the marker
high and low level accuracy
Test record
Photocopy the test record and use it to record the performance test results. (See
page 2-35, Test record.)
2–22 AWG70000A Series and AWGSYNC01 Technical Reference
