Specifications
Table 1-11: Pha
se noise with jitter reduction, AWG70002A operating at 8 GS/s
Analog output frequency
Offset 100 MHz 1 GHz 2 GHz 3 GHz
100 Hz
–110 dBc/Hz –89 dBc/Hz –83 dBc/Hz –80 dBc/Hz
1kHz
–127 dBc / Hz –109 dBc / Hz –102 dBc / Hz –99 dBc / Hz
10 kHz
–134 dBc/Hz –115 dBc/Hz –108 dBc/Hz –107 dBc/Hz
100 kHz
–134 dBc/Hz –113 dBc/Hz –106 dBc/Hz –104 dBc/Hz
1MHz
–142 dBc/Hz –121 dBc/Hz –114 dBc/Hz –112 dBc/Hz
10 MHz
–154 dBc/Hz –149 dBc/Hz –144 dBc/Hz –141 dBc/Hz
Table 1-12: Phase noise with jitter r eduction, AWG70002A operating at 16 GS/s
Analog output frequency
Offset 100 MHz 1 GHz 2 GHz 3 GHz 4 GHz
100 Hz
–112 dBc/Hz –90 dBc/Hz –87 dBc/Hz –82 dBc/Hz –80 dBc/Hz
1kHz
–128 dBc / Hz –109 dBc / Hz –103 dBc / Hz –99 dBc / Hz –97 dBc / Hz
10 kHz
–134 dBc/Hz –116 dBc/Hz –110 dBc/Hz –106 dBc/Hz –104 dBc/Hz
100 kHz
–133 dBc/Hz –113 dBc/Hz –108 dBc/Hz –104 dBc/Hz –101 dBc/Hz
1MHz
–141 dBc/Hz –122 dBc/Hz –116 dBc/Hz –113 dBc/Hz –110 dBc/Hz
10 MHz
–154 dBc/Hz –150 dBc/Hz –147 dBc/Hz –143 dBc/Hz –140 dBc/Hz
Table 1-13: Phase noise without jitter reduction, AWG70001A operating at 49.998998 GS/s
An
alog output frequency
O
ffset
1
00 MHz
1
GHz
1
0GHz
1
6GHz
100 Hz
–
110 dBc/Hz
–
89 dBc/Hz
–
69 dBc/Hz
–
67 dBc/Hz
1kHz
–125 dBc/Hz –105 dBc/Hz –84 dBc/Hz –82 dBc/Hz
10 kHz
–130 dBc/Hz –110 dBc/Hz –94 dBc/Hz –89 dBc/Hz
100 kHz
–126 dBc/Hz –106 dBc/Hz –89 dBc/Hz –85 dBc/Hz
1MHz
–139 dBc/Hz –119 dBc/Hz –104 dBc/Hz –100 dBc/Hz
10 MHz
–145 dBc/Hz –128 dBc/Hz –111 dBc/Hz –106 dBc/Hz
Table 1-14: Phase noise without jitter reduction, AWG70001A & AWG70002A operating at 24.998998 GS/s
Analog output frequency
Offset 100 MHz 1 GHz 10 G Hz
100 Hz
–104 dBc/Hz –92 dBc/Hz –74 dBc/Hz
1kHz
–124 dBc/Hz –105 dBc/Hz –83 dBc/Hz
10 kHz
–130 dBc/Hz –111 dBc/Hz –93 dBc/Hz
100 kHz
–126 dBc/Hz –106 dBc/Hz –89 dBc/Hz
1MHz
–131 dBc/Hz –122 dBc/Hz –104 dBc/Hz
10 MHz
–142 dBc/Hz –129 dBc/Hz –109 dBc/Hz
AWG70000A Series and AWGSYNC01 Technical Reference 1–9
