Saving and Recal
ling Information
2. Click Waveform.
3. Click Options..., if you want to specify
the Waveform Data Range, FastFrame
Data Range, Wa
veform Detail, Data
Destination, Source, or Data Ordering;
otherwise, skip to step 4.
4. Select the Source.
5. You can either save the waveform as a
reference waveform in the instrument
memory or as a .wfm file in a W indows
directory. To save the waveform as a
reference, select Ref 1–4. To save as a
.wfm file, select the location where you
want to save the waveform.
6. If you are saving as a .wfm file, type in a
file name, or use the default.
7. Click Save.
Quick Tips
Sele
ct Auto-increment file name to save numerous similar waveforms without having to retype the entire name.
To q
uickly save multiple waveforms, select Set Front Panel Print Button to Save, and then click Save. You can now
save a waveform by pushing the front-panel Print button.
112 DPO7000 Series and DPO/DSA70000/B Series Q uick Start User Manual
