Pinpoint trigge
rs
SettingupActiononEvent
Action on Event allows configure the oscilloscope to save a variety of fileswhenadefined event takes place, such as a
trigger events, mask test failures, and limit test failures.
1. Select F ile > A ction on Event.
2. Select the event to use.
3. Select the action to take when the event
occurs. Select Save, Send E-mail, or
both.
Use the Setup button (next to Save) to
display the Save on Event Setup display
screen.
Use the Setup button (next to Send E-mail)
to display the Send E-mail Setup display
screen. (S ee page 85, Setting up E-Mail on
Event.)
4. Enter the location to save the files.
5. Select the event that initiates a save.
6. Select what type of filestosaveonthe
event.
7. Set the file naming convention to u se.
8. Set the number of events to save.
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 83
