Tektronix DPO70000C/DX Series User Manual

Appendix C
Appendix C
TPP0500 and TPP1000 500 MHz and 1 GHz 10X passive probes instructions
071-2809-xx
Copyright © Tektronix, Inc. All rights reserved.
Operating information
The TPP0500 & TPP1000 10X Passive Probes are compact passive probes with 10X attenuation that are designed for use
with Tektronix MSO/DPO 4000B & 5000 Series oscilloscopes.
The probes have no user- or Tektronix-serviceable parts.
Connecti
ng the probe to the oscilloscope
Connect the probe as shown in the illustrations below.
176 MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO /DP O5000 Series U ser Manual
