Display a wavefo
rm
2. Push HORIZ or VERT to select wh ich
axis to magnify in the zoom graticule.
Use the multip
urpose knobs to adjust
scale and position of the magnified
waveform.
In this ex am p
le the main graticule is
the top half of the graticule and the
zoomed graticule is the bottom half of
the graticul
e.
NOTE. You can hide or display zoomed
waveforms by pressing Show/Hide
Waveforms a
nd then checking which
zoomed waveforms to display.
3. To adjust the zoom graticule size, select
Zoom Graticule Size from either the
Vertical
or Horiz/Acq menus.
4. If MultiV
iew Zoom is on but the readouts
are not attached to the zoom controls,
press the MultiView Zoom button to
attach t
he readouts to the zoom controls.
Press the MultiView Zoom button again
to turn zoom off.
Quick tips
Use the Zoom Setup menu to change the graticule size of the zoomed waveform.
Use Wave Inspector to m anage long record length w aveforms. (See page 102, Using Wave Inspector to manage
long record length waveforms.)
