Tektronix DPO70000C/DX Series User Manual

Display a wavefo
rm
6. To adjust the zo
omed area vertically,
select Vertical > Zoom Setup...,
click a vertical field, and then use the
multipurpose
knobs to adjust the Vertical
Position and Factor.
Quick tips
To clear th
e zoom area, click Position Factor Reset from the Zoom Setup control window.
Turn each
zoom display on and off from the Zoom Setup control w indow.
Push the M
ultiView Zoom button once or twice to toggle all zoom displays on and off.
To reposi
tion the zoomed area horizontally, click and drag th e horizontal marker at the bottom of the zoom box.
Use Wave
Inspector to manage long record length w aveforms. (See page 102, Using Wave Inspector to m anage
long record length waveforms.)
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 99
