Run application
software
Use ST1G or ST6G S erial Protocol Trigger Software to trigger and decode NRZ serial data (ST1G) and 8B/10B data on
high-speed ser
ial or data protocols (ST6G). Protocol triggering up to 6.25 GS/s (with ST6G).
Use SVP, SVM,a
nd SVE Spectral Analysis application to validate wideband designs and characterize wideband
spectral events.
Use SVO for flexible OFDM analysis, requires SVE.
Use SVT for settling time measurements (frequency and phase), requires SVE.
Use USB to characterize USB 2.0 signals including mask testing and parametric testing.
Use USB3 to verify, characterize, debug, and compliance test U SB 3.0 systems (requires option DJA).
Use VET to enable visual trigger and search.
Use XGBT for 10 GBASE-T Ethernet physical medium attachment (PMA) physical-layer (PHY) electrical compliance
testing.
Follow the instructions provided with the
applicati
on software to i nstall it. To run the
software, select Analyze and then select the
application.
164 MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO /DP O5000 Series U ser Manual
