Tektronix DPO70000C/DX Series User Manual

Acquisition
Multiple frames are best viewed with the Normal, Green, or G ray color palettes because the dark blue selected frame
may be hard to di
stinguish if you use Temp or Spectral.
If you select a
n Average Summary Frame, you can set Math functions (Averaging) to apply to All Frames or have it
apply to Only the Summary Frame. If the summary data is of primary interest, selecting Summary Frame Only can
substantially improve system throughput.
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 63
