Trigger on Q-Tag Control Information

For Trigger on Q-Tag Control Information you need to specify the Q-tag Value.

Trigger on MAC Length/Type

For Trigger on MAC Length/Type you need to specify the MAC length and type.

Trigger on IPv4 Header

For Trigger on IPv4 Header you need to enter the IP Protocol, Source Address, and the Destination Address.

Trigger setups
