Using tek LXI. Tek LXI conforms to the LAN eXtensions for Instrumentation (LXI) standard. The LXI standard defines the
communications protocols that allow communication with the instrument over a local area network (LAN). After the TekScope
application is running, the LXI application starts. The LXI system tray icon appears when LXI is running.
Right click on the icon and select Show LAN Status Indicator. LAN status is indicated in red or green with an appropriate
message.
NOTE. Pushing the LAN Reset button does a LAN configuration initialization: enables DHCP, enables Auto-IP, enables ICMP
ping responder, sets the Web password to default (No password), and updates the LXI XML identification. Refer to the LXI
specification for more information.
Enter the IP Address in the Address Bar of your Web browser and click return. The browser finds and displays the instrument
home page. Instrument information, instrument network information, and instrument LXI information is displayed on the home
page. Click on the SUPPORT Help link to see help on the Welcome Web page.
About Tektronix oscilloscopes
24 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
