Commands Listed in Alphabetical Order
Arguments
ON enables hist
ogram counting on a waveform database created on the source
of the histogram.
OFF disables h
istogram counting on a waveform database; testing is done
“on the fly.”
NR1 set to 0 d
isables the histogram counting on a waveform database; any
other value enables histogram counting on a waveform database.
Examples
HISTOGRAM:WFMDB:STATE ON enables histogram counting on a waveform
database.
HISTOGRAM:WFMDB:STATE? might return HISTOGRAM:WFMDB:STATE 0,
indicating that the histogram counting on a waveform database is disabled.
NOTE. A query always returns 0 or 1.
HORizontal? (Query Only)
This query o nly command returns all settings for the horizontal commands.
Group
Horizontal
Syntax
HORizontal?
Examples
HORIZONTAL? might return the following string (partial):
HORIZONTAL:TBMODE LOCKINT; UNITS S; BITS:STANDARD OC192;
BITRATE 9.95328000000E+009; HORIZONTAL:EXT10MHZREF:FREQ
10.0000000000E+006; HORIZONTAL:MAIN :SCALE
5.00000000000E-009; POSITION 8116300000000.009;
RESOLUTION 1
2.50000000000E–012; RECORDLENGTH 4000;REFPOINT
1.00000000000; TOLPOINT 81.16300000000E–009; TO FPOINT
31.16300000000E–009; HORIZONTAL:MAG NIFY1:SCALE
2.00000000000E–009; POSITION 51.16300000000E–009;
RESOLUTION 10.00000000000E–012; RECORDLENGTH 20 00;REFPOINT
1.00000000000; VIEW 1; TOLPOINT 51.16300000000E–009;
TOFPOINT 3
1.16300000000E–009; HORIZONTAL:MAGNIF Y2:SCALE
3.30000000000E–011; POSITION 31.21300000000E–009;
RESOLUTION 220.00000000000E–015; RECORDLENGTH 1 000;REFPOINT
150.00000000000E–003; VIEW 0;TOLPOINT 31. 49300000000E–00 9;
TOFPOINT 31.16300000000E-009;
...
DSA/CSA/TDS8X00/B Series Programmer Manual 2-153
