Commands Listed in Alphabetical Order
Syntax
HORizontal:BI
TS:STANdard { NONe | ATARXG1 | ATARXG2 |
ATARXG3 | ATATXG1 | ATATXG2 | ATATXG3 | ENET40GB_LR4
| ENET4 0GB_SR4 | ENET100GB_ER4 | ENET100GB_LR4 |
ENET100GB_SR
10 | ENET1250 | ENET2500 | ENET3125 | ENET9953
| ENET1 0313 | ENET11096 | ENET41250 | FC133 | FC133E
| FC266 | FC266E | FC531 | FC531E | FC1063 | FC1063E
| FC212 5 | FC21
25E_ABR| FC2125E_ABT | FC2125E_AGR |
FC2125E_AGT | FC4250E_ ABR | FC4250E_ABT | FC4250E_AGR
| FC425 0E_AGT | FC8500D | FC8500E_ABR | FC8500E_ABT |
FC8500E_AGR |
FC8500E_AGT| FC8500FINAL | FC4250 | FC10519
| FC113 17 | FC14025 _MMR6_1 | FC14025_SMR6_1 | FEC2666
| FEC10 664 | FEC107 09 | FEC42657 | FEC43018 | INF2500
| INFIE 25 | IN
FIniband | OC1 | OC3 | OC9 | OC12 | OC18
| OC24 | OC36 | OC48 | OC192 | OC768 | PCIEXPRESS_Rcv
| PCIEX PRESS50_Rcv | RIO_SERIAL1G | RIO_SERIAL2G |
RIO_SERIAL3
G | SAS3_0_XR | SAS3_0_XR_AASJ | SAS3_0_SATA
|USERMask|XFI9950_TAA|XFI9 950_RAD | XFI9950_THB |
XFI9950_RHC | XFI9950_ TMBP | XFI9950_RMCP | XAUIFar |
XAUIRFar | XA
UINear| X AUIRNear}
HORizontal:BITS:STANdard?
Arguments
NONe disables the communications standards.
ATARXG1 selects the Serial ATA, G1 Rx, 1.5 Gb/s bit rate and mask.
ATARXG2 selects the Serial ATA, G2 Rx, 3 Gb/s bit rate and mask.
ATARXG3 selects the Serial ATA, G2 Rx, 6 Gb/s bit rate and mask.
ATATXG1 selects the Serial ATA, G1 Tx, 1.5 Gb/s bit rate and mask.
ATATXG2 selects the Serial ATA, G2 Tx, 3 Gb/s bit rate and mask.
ATATXG3 selects the Serial ATA, G2 Tx, 6 Gb/s bit rate and mask.
ENET40GB_LR4 selects the 10.3125 Gb/s bit rate and mask, in accordance
with the Ethernet 40GBASE-LR4 standard.
ENET40GB_SR4 selects the 10.3125 Gb/s bit rate and mask, in accordance
with the Ethernet 40GBASE-SR4 standard.
ENET100GB_ER4 selects the 27.78125 Gb/s bit rate and mask, in accordance
with the Ethernet 100GBASE-ER4 standard.
ENET100GB_LR4 selects the 27.78125 Gb/s bit rate and mask, in accordance
with the Ethernet 100GBASE-LR4 standard.
ENET100GB_SR10 selects the 10.3125 Gb/s bit rate and mask, in accordance
with the Ethernet 100GBASE-SR10 standard.
ENET1250 selects the 1.250 Gb/s b it rate and mask, in accordance with the
IEEE 802.3 standard.
ENET2500 selects the 2.500 Gb/s bit rate (2x Gigabit Ethernet) and mask.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-155
