Commands Listed in Alphabetical Order
with the compar
tment in which the Phase Ref Module is installed. You can use
either of the two channels associated with the compartment. For example, if the
module is installed in the CH 7/CH8 compartment, x can be 7 or 8.
The guaranteed operation r ange of the Phase Reference Module is:
Standard 82
A04: from 8E+09 to 25E+09
Option 6 0G-equipped 82A04: from 8E+09 to 60E+09
NOTE. The a
llowed range of values that is accepted is larger than the guaranteed
range that's supported. See the PHAseref:CH<x>:FREQuency command for
more information.
Group
Phase Reference
Syntax
PHAseref:CH<x>:RANge?
Related Commands
PHAseref:CH<x>:FREQuency, PHAseref:CHAR, PHAseref:MODe,
PHAse
ref:SOUrce, PHAseref:CH<x>:STAtus?
Examples
PHASEREF:CH2:PRANGE? might return 8.000GHZ-60.00GHZ for 82A04 module
that
's equipped with Option 60G and that is installed in the C1C2 small module
compartment.
2-264 DSA/CSA/TDS8X00/B Series Programmer Manual
