Commands Listed in Alphabetical Order
NOTE. You shoul
ddefine a math waveform before turning the waveform on.
Group
Vertical
Syntax
SELect:CONTROl {CH<x> | MATH<x> | REF<x> | NONE}, {MAIn |
MAG1 | MAG2}
SELect:CONTROl?
Related Commands
SELect:CH<x>
Arguments
CH<x> selec t s the specified channel waveform as the waveform that is affected
by the front-panel controls. The range for x is 1 through 8.
MATH<x> selects the specified math waveform as the waveform that i s affected
by the front-panel controls. The range for x is 1 through 8.
REF<x> sele cts the specified reference w aveform as the waveform that is
affected by the front-panel controls. The range for x is 1 through 8.
NONE causes the instrument to do not hing. When returned in a query, NONE
indicates that no waveforms are associated with the front-panel controls.
MAIn selects Main as the timebase for the specified waveform.
MAG1 selects MAG1 as the timebase for the specified waveform.
MAG2 selects MAG2 as the timebase for the specified waveform.
Examples
SELECT:CONTROL CH1,MAIN selects the Channel 1 acquisition waveform as
the waveform affect
ed by the front-panel controls. This waveform is displayed
using the main timebase.
SELECT:CONTROL? m
ight return
SELECT:CONTROL math5,main, indicating
that the Math 5 waveform is currently affected by the fr ont-panel controls and
is displayed using the main timebase.
SELECT:CONTROL? might return SELECT :CONTROL NONE,MAIN, indicating that
no waveform using the Main timebase is controlled by front-panel controls.
SELect:MATH<x
>
This command sets or queries whether the specified math waveform is displayed.
The waveform is specified by x, which can be 1 through 8. This command is
the equivalen
ttoselectingamathwaveformandcheckingtheOncontrolinthe
Waveform section of the Vertical Setup dialog box.
2-276 DSA/CSA/TDS8X00/B Series Programmer Manual
