Tektronix DSA8200 Series User Manual

Commands Listed in Alphabetical Order
TRIGger:CLKR
ec:CRC:CLOCKAmplitude
This command sets or queries the clock output amplitude (in mV) of the connected
Clock Recovery instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:CLOCKA mplitude <NR3>
TRIGger:CLKRec:CRC:CLOCKA mplitude?
Arguments
NR3 is the clock output amplitude. The range is 250 mV to 900 mV.
Examples
TRIGGER:CLKREC:CRC:CLOCKA MPLITUDE 250E-3 sets the clock output
amplitude to 250 mV.
TRIGGER:CLKREC:CRC:CLOCKA MPLITUDE? might return
:TRIGGER:CLKREC:CRC:CLOCK AMPLITUDE 0.90
000000000
,
indicating that the clock amplitude is set to 900 mV.
NOTE. NAN is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:CLOCKOutput
This command sets or queries the clock out
put mode of the connected Clock
Recovery instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:CLOCKO utput {ON | OFF | <NR1>}
TRIGger:CLKRec:CRC:CLOCKO utput?
Arguments
ON enables the clock output on the Clock Recovery instrument.
OFF disables the clock output on the Clock Recovery instrument.
<NR1>. 1 enables the clock output. 0 disables the clock output.
Examples
TRIGGER:CLKREC:CRC:CLOCKO UTPUT ON enables the clock output of the Clock
Recovery instrument.
2-310 DSA/CSA/TDS8X00/B Series Programmer Manual
