Commands Listed in Alphabetical Order
Syntax
TRIGger:CLKRe
c:CRC:LOCKFp { ON | OFF }
Ar
guments
ON locks the clock recovery instrument front panel controls.
OFF unlocks the clock recovery instrument front panel controls.
Examples
TRIGGER:CLKREC:CRC:LOCKFP
TRIGger:CLKRec:CRC:LOCKMode
This command sets or queries the lock mode of the connected Clock Recovery
instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:LOCKMod e {MANual | AUTOmatic}
TRIGger:CLKRec:CRC:LOCKMod e?
Arguments
MANual forces the Clock Recovery instrument to attempt to acquire a signal
lock.
AUTOmatic sets the Clock Recovery instrument to automatically re-acquire a
signal lock if the phase error exceeds the set limits or the recovered c lock is
unstable. This is
the default setting.
Examples
TRIGGER:CLKREC:CRC:LOCKMOD E AUTOMAT IC sets the signal lock mode of the
Clock Recovery instrument to automatic.
TRIGGER:CLKREC:CRC:LOCKMOD E? might return
:TRIGGER:CLKREC:CRC:LOCKMO DE AUTO, indicating that the lock mode is
set to the automatic setting.
NOTE. AUTOMATIC is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:LOCKRange
This command sets or queries the locking range (in Hz) about the nominal
frequency setting of the connected Clock Recovery instrument.
Group
Trigger
DSA/CSA/TDS8X00/B Series Programmer Manual 2-317
