Tektronix DSA8200 Series User Manual

Commands Listed in Alphabetical Order
Arguments
NR3 sets the e dg
e density value. The range is from 10% to 100%
Examples
TRIGGER:CLKREC:CRC:NOMEDG EDENSITY 50 sets the edge density value to
50%.
TRIGGER:CLKREC:CRC:NOMEDG EDENSITY? might return
:TRIGGER:CLKREC:CRC:NOMED GEDENSITY 50.00000000000,
indicating that the current edge density is set to 50%.
NOTE. NAN is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:NOMFrequency
This command sets or queries the nominal frequency setting (in Hz) of
the
connected Clock Recovery instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:NOMFre quency <NR3>
TRIGger:CLKRec:CRC:NOMFre quency?
Arguments
NR3 is the nominal frequency value. The frequency range is 150 MHz to 12.5
GHz.
Examples
TRIGGER:CLKREC:CRC:NOMFRE QUENCY 1 2.5E9 sets the nominal frequency of
the Clock Recovery Instrument to 12.5 GHz.
TRIGGER:CLKREC:CRC:NOMFRE QUENCY? might return
:TRIGGER:CLKREC:CRC:NOMFREQUENCY 12.00000000000E9,
indicating that the nominal frequency of the Clock Recovery instrument is set to
12 GHz.
NOTE. NAN is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:PEAKing
This command sets or queries the peak range (in dB) of the connected Clock
Recovery instrument.
Group
Trigger
2-320 DSA/CSA/TDS8X00/B Series Programmer Manual
