Commands Listed in Alphabetical Order
Syntax
TRIGger:CLKRe
c:CRC:LOOPBandwidth <NR3>
TRIGger:CLKRec:CRC:LOOPBan dwidth?
Arguments
NR3 sets the loop bandwidth. The range is 100E3 to 12E6.
Examples
TRIGGER:CLKREC:CRC:LOOPBAN DWIDTH 100E4 sets the loop bandwidth to
1MHz.
TRIGGER:CLKREC:CRC:LOOPBAN DWIDTH? might return
:TRIGGER:CLKREC:CRC:LOOPBA NDWIDTH 7.19800000000E6,
indicating that the loop bandwidth is set to 7.198 MHz.
NOTE. NAN is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:MODElnum? (Query Only)
Returns a string with the clock recovery instrument information.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:MODElnu m?
Examples
TRIGGER:CLKREC:CRC:MODELNU M? might return BERTScope DCRJ, indicating
that the current clock recovery instrument is a BERTSCope that supports jitter
analysis.
TRIGger:CLKRec:CRC:NOMEDgedensity
This command sets or queries the nominal edge density (in percent) of the
connected Clock R ecovery instrument. The edge density refers to the average
percentage of unit intervals which contain a transition.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:NOMEDge density <NR3>
TRIGger:CLKRec:CRC:NOMEDge density?
Related Commands
TRIGger:CLKRec:CRC:EDGEDENSITYMode
DSA/CSA/TDS8X00/B Series Programmer Manual 2-319
