Commands Listed in Alphabetical Order
Arguments
QString is a quo
ted string that definesadevicenamefortheClockRecovery
instrument. The device name can be from 1 to 11 characters and is case sensitive.
Examples
TRIGGER:CLKREC:CRC:DEVICEN AME "TEK_80A07" sets the name of the
connected Clock Recovery instrument to TEK_80A07.
TRIGGER:CLKREC:CRC:DEVICEN AME? might return
:TRIGGER:CLKREC:CRC:DEVICE NAME TEK_80A07 indicating that the name of
the currently
connected Clock Recovery instrument is TEK_80A07.
NOTE. undefined is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:EDGEDensity? (Query Only)
This query only c ommand returns the measured edge density (in percent) from the
connected
Clock Recovery instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:EDGEDen sity?
Examples
TRIGGER:CLKREC:CRC:EDGEDEN SITY? might return
:TRIGGER:CLKREC:CRC:EDGEDE NSITY 31.11091041565, indicating that
the edge density is 31.11%.
NOTE. NAN is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:EDGEDENSITYMode
This command sets or queries the edge density mode setting of the connected
Clock Recovery instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:EDGEDEN SITYMode {NOMinal | ON_Lock}
TRIGger:CLKRec:CRC:EDGEDEN SITYMode?
Related Commands
TRIGger:CLKRec:CRC:NOMEDgedensity
DSA/CSA/TDS8X00/B Series Programmer Manual 2-313
