Commands Listed in Alphabetical Order
NOTE. undefined
is returned if a Clock Recovery instrument is not present.
TRIGger:CLKR
ec:CRC:SUBCLOCKAmpl
This command sets or queries the sub-rate clock output amplitude (in mV) of the
connected Clock Recovery instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:SUBCLO CKAmpl <NR3>
TRIGger:CLKRec:CRC:SUBCLO CKAmpl?
Arguments
NR3 sets the sub-rate clock output amplitude. The range is 2 50 mV to 900 mV.
Examples
TRIGGER:CLKREC:CRC:SUBCLO CKAMPL 300E-3 sets the sub-rate clock output
amplitude to 300 mV.
TRIGGER:CLKREC:CRC:SUBCLO CKAMPL? might return
:TRIGGER:CLKREC:CRC:SUBCL OCKAMPL 0.50000000000,
indicating that the sub-rate clock output amplitude is 500 mV.
NOTE. NAN is returned if a Clock Recovery instrument is not present.
TRIGger:CLKRec:CRC:SUBCLOCKDiv
This command sets o r queries the division ratio of the sub-rate clock of the
connected Clock Recovery instrument.
Group
Trigger
Syntax
TRIGger:CLKRec:CRC:SUBCLO CKDiv <NR1>
TRIGger:CLKRec:CRC:SUBCLO CKDiv?
2-326 DSA/CSA/TDS8X00/B Series Programmer Manual
