Commands Listed in Alphabetical Order
WFMDB:DISPLAY
:EMPHASIS?
might return WFMDB: DISPLAY:EMPHASIS 50,
indicating that the Emphasize Counts is set to 50%.
WFMDB:DISplay:GRADing
This command sets o r queries which grading type (color or intensity) the
instrument uses to draw the WfmDB. This is equivalent to selecting Color or
Intensity for Grading in the Display Options section of the WfmDB Setup dialog
box.
Group
Waveform Database
Syntax
WFMDB:DISplay:GRADing {COLor | INTensity}
WFMDB:DISplay:GRADing?
Related Commands
WFMDB:DISplay:EMPHasis, WFMDB:DISplay:INVert
Arguments
COLor maps the WfmDB display to colors. This is the d efault setting.
INTensity maps the WfmDB display to intensity.
Examples
WFMDB:DISPLAY:GRADING COLOR sets the grading type for the WfmDB to
color.
WFMDB:DISPLAY:GRADING? might return WFMDB:DISPLAY:GRA DING
INTENSITY
, indicating that the grading type for the WfmDB display is set to
intensity.
WFMDB:DISplay:GRADMethod
This command sets or queries the grading method that waveform databases use to
display the data they contain. For example, setting an emphasis mode displays
data so it is graded by count frequencies in respect to the bin levels in which
the data accumulates.
Use of this command is equivalent to selecting Grading Method in the Display
Options section of the Wfm Database Setup dialog box.
Group
Waveform Database
Syntax
WFMDB:DISplay:GRADMethod {EMPH8 | EMPH7 | BIN8 | BIN7}
WFMDB:DISplay:GRADMethod?
DSA/CSA/TDS8X00/B Series Programmer Manual 2-347
