Commands Listed in Alphabetical Order
box in the Datab
ase section of the Wfm Database Setup dialog box. Use
the WFMDB:WFMDB<x>:DISplay command to control whether or not the
waveform database is displayed.
Group
Waveform Database
Syntax
WFMDB:WFMDB<x>:ENABle { ON | OFF | NR1 }
WFMDB:WFMDB<x>:ENABle?
Related Commands
WFMDB:WFMDB<x>:DISplay
Arguments
ON enables the display o f the specified WfmDB waveform.
OFF disables the display of the specified WfmDB waveform. This is the
default setting.
NR1 set to 0 disables the display of the specified WfmDB waveform; any other
integer value enables the display of the specified WfmDB waveform.
Examples
WFMDB:WFMDB1:ENABLE ON enables the waveform display for Database 1.
WFMDB:WFMDB2:ENABLE? might return WFMDB:WFMDB2:ENABLE 0, indicating
that the Database 2 waveform display is disabled.
NOTE. This query always returns a 0 or 1.
WFMDB:WFMDB<x>:PERSistence:COUNt
This command sets or queries the Variable-persistence waveform count for the
specified WfmDB. The WfmDB is spe cified by x, which can be 1 through 4. The
count applies to the Variable persistence mode, which can be selected with the
comma
nd WFMDB:WFMDB<x>:PERSistence:MODe VARPersist.
Use of this command is equivalent to entering a value in the Waveforms Edit Box
in th
e Persistence section of the Wfm Database Setup dialog box.
Group
Waveform Database
Syntax
WFMDB:WFMDB<x>:PERSistence :COUNt <nr1>
WFMDB:WFMDB<x>:PERSistence :COUNt?
DSA/CSA/TDS8X00/B Series Programmer Manual 2-351
