Commands Listed in Alphabetical Order
Group
Waveform Datab
ase
Syntax
WFMDB:WFMDB<x>:CLEar
Related Commands
ACQuire:DATA:CLEar
Examples
WFMDB:WFMDB1:CLEAR clears the counts in WfmDB 1 (Waveform Database1).
WFMDB:WFMDB<x>:DISplay
This command displays the specified WfmDB waveform. The query form of this
command returns whether or not
the specified WfmDB waveform is displayed.
The WfmDB is specified by x, which can be 1 through 4. This command is the
equivalent to checking or unchecking the Display box in the Database section of
the Wfm Database Setup dialog box.
Group
Waveform Database
Syntax
WFMDB:WFMDB<x>:DISplay { ON | OFF | NR1 }
WFMDB:WFMDB<x>:DISplay?
Arguments
ON enables the display of the specified WfmDB waveform.
OFF disables the display of the specified WfmDB waveform. This is the
default setting.
NR1 set t o 0 disables the display of the specified WfmDB waveform; any other
integer value enables the display of the specified WfmDB waveform.
Examples
WFMDB:WFMDB1:DISPLAY ON enables the waveform display for Database 1.
WFMDB:WFMDB2:DISPLAY? might return WF MDB:WFMDB2:DISPLAY 0,
indicating that the Database 2 waveform display is disabled.
NOTE. This query always returns a 0 or 1.
WFMDB:WFMDB<x>:ENABle
This command sets or queries whether the specified waveform database
(WfmDB) is enabled. The WfmDB is specified by x, which can be 1 through
4. This command is the equivalent to selecting or deselecting the On check
2-350 DSA/CSA/TDS8X00/B Series Programmer Manual
