Commands Listed in Alphabetical Order
Group
Waveform Datab
ase
Syntax
WFMDB:DISplay:I
NVert { ON | OFF | NR1 }
WFMDB:DISplay:INVert?
Related Commands
WFMDB:DISplay:EMPHasis, WFMDB:DISplay:GRADing
Arguments
ON enables the invert function.
OF
F
disables the invert function.
NR1 set to 0 disables on the invert function; any other integer enables the
i
nvert function.
Examples
WFMDB:DISPLAY:INVERT ON enables the invert function.
WFMDB:DISPLAY:INVERT? might return WFMDB:DISPLAY:INVERT 0,
indicating that the invert function is disabled.
NOTE. This query always returns 0 or 1.
WFMDB:WFMDB<x>? (Query Only)
This query only command returns the waveform database parameters for the
WfmDB specified by x, which can be 1 through 4.
Group
Waveform Database
Syntax
WFMDB:WFMDB<x>?
Examples
WFMDB:WFMDB2? might return WFMDB:W FMDB2:SOURCE REF1,MAIN;DISPLAY
1;ENABLE 1;PERSISTENCE:MODE INFPERSIST;COUNT 523;SAMPLES
130750
.
WFMDB:WFMDB<x>:CLEar (No Query Form)
This command (no query form) resets to zero (clears) the counts in the specified
WfmDB. The WfmDB is specified by x, which can be 1 through 4. (Sending the
ACQuire:DATA:CLEAR command has the same effect on the WfmDB.)
DSA/CSA/TDS8X00/B Series Programmer Manual 2-349
