Commands Listed in Alphabetical Order
Arguments
CH<x> selects a
channel waveform as the source for the specified WfmDB.
The range for x is 1 through 8.
MATH<x> selects a math waveform as the source f or the spec ified WfmDB.
The range for x is 1 through 8.
MAIn (optional) selects Main as the timebase for the specified WfmDB
display. This is the default timebase.
MAG1 (optional) selects MAG1 as the timebase for the specified WfmDB
display.
MAG2 (optional) selects MAG2 as the timebase for the specified WfmDB
display.
Examples
WFMDB:WFMDB1:SOURCE CH4 sets Channel 4, Main timebase, as the source
for WfmDb1.
WFMDB:WFMDB2:SOURCE? might return WFMDB:WFMDB 2:SOURCE MATH2,MAIN,
indicating that the Math 2 waveform is set as the source for WfmDB2 and is
displayed with the M ain timebase.
WFMInpre? (Query Only)
This is a query only that returns the waveform formatting data (preamble) for
the incoming waveform.
Group
Waveform Transfer
Syntax
WFMInpre?
Examples
WFMINPRE? might return WFMINPRE:ENCDG ASCII;BN_FMT RI;BYT_OR
LSB;BYT_NR 4;BIT_NR 32 ;NR_PT 500;PT_FMT Y;X INCR
1.00000000000E-006;XZERO 16.00000000008E- 009;XUNIT
"";YMULT 0.100000000000;XMULT 100.00000000000E-012;XOFF
65.00000000008E-009;YZERO 1.00000000000E- 006;YSCALE
5.00000000000E-003;YOFF -2;YUNIT "";WFMLABEL ""
.
WFMInpre:BIT_Nr? (Query Only)
This query only command returns the number of bits (width) per waveform point
for the waveform to be transferred to the instrument.
NOTE. This instrument supports only the 32-bit format.
2-354 DSA/CSA/TDS8X00/B Series Programmer Manual
