Status and Events
Table 3-5: Execution Error Messages (EXE Bit 4) (cont.)
Code Message
2202
Measurement error, No period found
2203
Measurement error, No period, second waveform
2204 Measurement error, Low signal amplitude
2205 Measurement error, Low amplitude
2206 Measurement error, Invalid gate
2207
Measurement error, Measurement overflow
2208
Measurement error, Waveform does not cross Mid Ref
2209
Measurement error, No second Mid Ref crossing
2210
Measurement error, No Mid Ref crossing, second waveform
2211
Measurement error, No backwards Mid Ref Crossing
2212 Measurement error, No negative crossing
2213 Measurement error, No positive crossing
2214 Measurement error, No crossing
2215
Measurement error, No crossing, second waveform
2216
Measurement error, No crossing, target waveform
2217
Measurement error, Constant waveform
2218 Measurement error, Unused
2219 Measurement error, No valid edge – No arm sample
2220 Measurement error, No valid edge – No arm cross
2221 Measurement error, No valid edge – No trigger cross
2222 Measurement error, No valid edge – N o second cross
2223
Measurement error, Waveform mismatch
2224 Measurement error, WAIT calculating
2225
Measurement error, No waveform to measure
2226
Measurement error, Null Waveform
2227
Measurement error, Positive and Negative Clipping
2228
Measurement error, Positive Clipping
2229
Measurement error, Negative Clipping
2230
Measurement error, High Ref < Low Ref
2231 Measurement error, no statistics available
2235 Math error, Invalid math description
2236
Math error, Reference waveform is invalid
2237
Math error, Out of acquisition memory
2241
Waveform request is invalid
2243
This measurement cannot be performed on this type of waveform
2244
Source waveform is not active
2245
Saveref error, Selected channel is turned off
3-14 DSA/CSA/TDS8X00/B Series Programmer Manual
