Table 2-47: Digital Collection: 8 Byte Data (cont.)

Bit N umber D escription

CH1 transition state M SB

D15transitionstateMSB

...

D1 transition state MSB

D0 transition state MSB

31 — 20 not used

CH4 transition state LSB

CH3 transition state LSB

CH2 transition state LSB

CH1 transition state LSB

D15 transition state LS B

...

D1 transition state LSB

D0 transition state LSB

For example, to ﬁnd the transition state of the digital channel D0, set

DATa:SOUrce to

DIGITAL and DATa:WIDth to 8. Look at bits 0 and 32 in the

ata returned by the

CURVe? or WAVFrm? queries, where bit 0 is the transition

state LSB and bit 32 is the transition state MSB for D0.

2-104 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
