Command Groups
Table 2-37: RF Commands (cont.)
Item Description
SEARCH:SPECTral:LIST? This query will return a list of all automatically placed peak markers displayed in the frequency
domain graticule. (To return information about manual markers, use the MARKER:M<x>
commands.)
SELect:RF_AMPlitude This command switches the RF Amplitude vs. Timetracedisplayonoroffinthetimedomain
graticule.
SELect:RF_AVErage This command switches the R F Average trace display on or off in the frequency domain
graticule.
SELect:RF_FREQuency This command switches the RF Frequency vs. Time trace display on or off in the time domain
graticule.
SELect:RF_MAXHold This command switches the frequency domain Max Hold trace display on or off in the
frequency domain graticule.
SELect:RF_MINHold This command switches the frequency domain Min Hold trace display on or off in the frequency
domain graticule.
SELect:RF_NORMal This command switches the frequency domain Normal trace display on or off in the frequency
domain graticule.
SELect:RF_PHASe This command switches the RF Phase vs. Time trace display on or off in the time domain
graticule.
Save and Recall Command Group
UsethecommandsintheSaveandRecallCommand Group to store and retrieve
wav
eforms and settings. When you save a setup, you save all the settings of the
oscilloscope. When you recall a setup, the oscilloscope restores itself tothestate
it was in when you originally saved the setting.
NOTE. External filestructureisasfollows:
E: is the USB memory device plugged into the first USB port on the front of the
oscilloscope.
F: is the USB memory device plugged into the second USB port on the front of the
oscilloscope. (Not available for MDO3000 models).
G: and H: are the USB memory device plugged into the USB ports on the rear o f
the oscilloscope. (Not available for MDO3000 models.)
I: — Z are for network storage.
2-58 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
