Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
Group
Trigger
Syntax
TRIGger:A:VIDeo:STANdard {NTSc|PAL|SECAM|BILevelcu stom|
TRILevelcustom| HD480P60|HD576P50|HD720P30|HD72 0P50
|HD720P60|HD875I60|HD1080P24|HD1080SF2 4|HD1080I50
|HD1080I60|HD1080P25|HD1080P30|HD1080P 50|HD1080P60}
TRIGger:A:VIDeo:STANdard?
Related Commands
TRIGger:A:VIDeo:CUSTom{:FORMat|:TYPe}, TRIGger:A:VIDeo:CUSTom:
LINEPeriod, TRIGger:A:VIDeo:CUSTom:SYNCInterval
Arguments
NTSc sets the oscilloscope to trigger on video signals that meet the NTSC
525/60/2:1 standard (a line rate of 525 lines per frame and a field rate of 60 Hz).
PAL sets the oscilloscope to trigger on video signals that meet the NTSC
625/50/2:1 standard (a line rate of 625 lines per frame and a field rate of 50 Hz).
SECAM sets the oscilloscope to trigger on video signals that meet the SECAM
standard.
BILevelcustom sets the oscilloscope to trigger on video horizontal scan rate
parameters defined by the TRIGger:A:VIDeo:CUSTom{:FORMat|:TYPe},
TRIGger:A:VIDeo:CUSTom:LINEPeriod and TRIGger:A:VIDeo:CUSTom:
SYNCInterval commands. (Requires installation of a DPO4VID application
module for 4000 series models.)
TRILevelcustom sets the oscilloscope to trigger on video horizontal scan rate
parameters defined by the TRIGger:A:VIDeo:CUSTom{:FORMat|:TYPe},
TRIGger:A:VIDeo:CUSTom:LINEPeriod command. (Requires installation of a
DPO4VID application module for 4000 series models.)
HD480P60|HD576P50|HD720P30|HD720P50|HD 720P60|HD875I60
|HD1080P24|HD1080SF24|HD1080I50|HD1080 I60|HD1080P25|HD1080P30
|HD1080P50|HD1080P60
set the oscilloscope to trigger on an HDTV video
signal that meets standards defined in the following table. (Requires installation
of a DPO4VID application module for 4000 series models.)
Table 2-57: Available HDTV formats
HDTV format Description
480p60
525 lines (480 active), 640 or 704 x 480
pixel, progressive, 60 fps
576p50
EDTV with 625 lines (576 active), 1024 x 576
pixel, progressive, 50 fps
720p30
750 lines (720 active), 1280 x 720 pixel,
progressive, 30 fps
2-918 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
