Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
Table 2-57: Available HDTV formats (cont.)
HDTV format Description
720p50
750 lines (720 active), 1280 x 720 pixel,
progressive, 50 fps
720p60
750 lines (720 active), 1280 x 720 pixel,
progressive, 60 fps
875i60
875 active lines, interlaced, 60 fps
1080i50
1125 Lines (1080 active), 1920 x 1080 pixel,
interlaced, 50 fps
1080i60
1125 lines (1080 active), 1920 x 1080 pixel,
interlaced, 60 fps
1080p24
1125 lines (1080 active), 1920 x 1080 pixel,
progressive, 24 fps
1080sF24
1125 lines (1080 active), 1920 x 1080 pixel,
progressive (sF), 24 fps
1080p25
1125 lines (1080 active), 1920 x 1080 pixel,
progressive, 25 fps
1080P30
1125 lines (1080 active), 1920 x 1080 pixel,
progressive, 30 fps
1080P50
1125 lines (1080 active), 1920 x 1080 pixel,
progressive, 50 fps
1080P60
1125 lines (1080 active), 1920 x 1080 pixel,
progressive, 60 fps
Examples
TRIGGER:A:VIDEO:STANDARD NTSC sets the oscilloscope to trigger on
NTSC-standard video signals.
TRIGGER:A:VIDEO:STANDARD? might return :TRIGger:A:VIDe o:STANDARD
NTSC
indicating that the oscilloscope is set to trigger on an NTSC format.
TRIGger:A:VIDeo{:SYNC|:FIELD}
This command sets the video field to use for triggering on video signals (odd
fields, even fields, all fields, all lines, numeric).
Conditions
This command requires a DPO4VID application module to use any standard
besides NTSc, PAL, or SECAM, except for MDO3000 models, which do not
require an application module.
Group
Trigger
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-919
