Commands Listed in Alphabetical Order
Table 2-54: FPAnel:PRESS arguments (cont.)
Argument Description
D15D0 D15–D0 button
DEFaultsetup
Default Setup button
FINe Fine button
FORCetrig
Force Trig button
HARDcopy Print button
HORZPos Push to center (MDO3000 and M DO4000C
only)
INTensity Intensity button
MAGnify Magnify (zoom) button (not the zoom/pan
knob)
MARk
MarkSet/Clear button
MATh M button
MENUOff Menu Off button
MEASurement
Measure button
NEXt Right arrow button
PAUse
Play/pause button
PREv
Left arrow button
REF R button
RMENU<x>
Screen side menu buttons, where <x>=1 for
top-most side menu button and <x>=5 for the
bottom-most side menu button
RUnstop
Run/Stop button
SAVEBUtton Save button
SAVERecall Save/Recall Menu button
SEArch Search button
SELect Select button
SINGleseq Single button
TESt
Test button
TRIGger
Trigger Menu button
TRIGLevel
Trigger Level knob – sets the trigger level to
the midpoint of the waveform.
VERTPOS1–4
Vertical position knob — push to center
(MDO3000 and MDO4000C only)
VERTSCALE1–4 Vertical scale knob — push for Fine
(MDO3000 and MDO4000C only)
UTILity Utility button
Examples
FPANEL:PRESS AUTOSET executes the oscilloscope Autoset function.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-329
