Commands Listed in Alphabetical Order
MASK:CUSTom (
No Query Form)
This command initializes a custom mask using a default triangle segment 1 mask
(
:MASK:CUSTOM INIT), or copies the currently active mask to the user-defined
custom mask (
:MASK:CUSTOM COPYActive).
NOTE. When you create a custom mask, t he horizontal position setting is
converted from percent to time, and sets the trigtosamp value. If you c hange
trigtosamp value a fter the mask has been displayed, the mask will be horizontally
offset, and the segment x values recalculated. Note that the segment x values are
the relative time between the trigger position and the mask point's x value.
A series of examples showing how to use mask commands for typical tasks
is included in an appendix. (See page E-1, Mask/Limit Command Sequence
Example
s.)
Conditions
This command requires a DPO4LMT application module for 4000 series models,
and an MDO3LMT application module for MDO3000 series models.
Group
Mask
Syntax
MASK:CUSTom {INIT|COPYACTive}
Related Commands
MASK:USER:AMPLitude,
MASK:USER:WIDth,
MASK:MARgin:PERCent
Arguments
INIT sets the user-defined custom mask to its initialized state.
COPYACTive copies the currently active mask to the user-defined custom mask.
Examples
MASK:CUSTom INIT creates an initialized user-defined custom mask.
MASK:DISplay
This command controls whether a mask is displayed on the screen. This is useful
for temporarily turning off masks without deleting them. This is equivalent to
pushing the bottom bezel "Setup Mask" button, and then pushing the side bezel
"Display Mask" button.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-375
