Commands Listed in Alphabetical Order
Array Name Leng
th (string length of name - e.g. 6 for IQData)
Array Name (including pad bytes which are 0's) (see Array Size above)
Array Data Element Type (4 bytes) = miSINGLE (7)
Size of Array (4 bytes) = (IQ record length) * 4
The I data values as 4-byte floating point values
Pad Bytes: 0 or more 0 bytes to end the record on an 8-byte boundary
The Q data i
s written next:
Data Type (4 bytes) = miSINGLE (7)
Size of Array (4 bytes) = (IQ record length) * 4
The Q data values as 4-byte floating point values
Pad Bytes: 0 or more 0 bytes to end the record on an 8-byte boundary
NOTE. The external file structure is as follows:
E: is the USB memory device plugged into the fi rst ( left) USB port on the front of
the oscilloscope.
F: is the USB memory device plugged into the second (right) U SB port on the
front of the oscilloscope. (Not available for MDO3000).
G: and H: are the USB memory device plugged into the USB ports on the rear o f
the oscilloscope. (Not available for MDO3000 models.)
I: – Z: are for network storage.
Group
Save and Recall
Syntax
SAVe:WAVEform <Source>,<Destination>
Related Commands
RECAll:WAVEform,
SAVe:WAVEform:FILEFormat
Arguments
<source> can be one of:
CH1-4, MATH, REF1-4 -
These sources can be saved to REF1-4, an ISF or CSV file. For instruments
with the arbitrary waveform feature, these sources can be saved to EMEM (edit
memory) with the restriction tha
t MATH and REF1-4 sources must be time
2-602 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
