WFMINPRE:YOFF
?
might return :WFMINPRE:YOFF 25 indicating the vertical
position of the incoming waveform is 25 digitizing levels.
WFMInpre:YUNit
This command specifies the vertical units of data points in the incoming waveform
record sent to the oscilloscope using the
CURVE command. This can be any of
several string values, depending upon the vertical units of the waveform being
sent.
Supported units are: %, /Hz, A, A/A, A/V, A/W, A/dB, A/s, AA, AW, AdB, As,
B, Hz, IRE
, S/s, V, V/A, V/V, V/W, V/dB, V/s, VV, VW, VdB, volts, Vs, W,
W/A, W/V, W/W, W/dB, W/s, WA, WV, WW, WdB, Ws, dB, dB/A, dB/V, dB/W,
dB/dB, dBA, dBV, dBW, dBdB, day, degrees, div, hr, min, ohms, percent, s
NOTE. (See page 2-95, Waveform Transfer Command Group.)
Group
Waveform Transfer
Syntax
WFMInpre:YUNit <QString>
WFMInpre:YUNit?
Related Commands
WFMOutpre:YUNit?
Arguments
<QString> contains the characters that represent the vertical units for the
incoming waveform.
Examples
WFMINPRE:YUNIT? might return :WFMINPRE:Y UNIT "V" indicating the vertical
units for the incoming waveform are volts.
WFMINPRE:YUNIT "A" specifies that the vertical units for the incoming waveform
are Amperes.
WFMInpre:YZEro
This command specifies the vertical offset of the destination reference waveform
in units speci
fiedbythe
WFMInpre:YUNit command. Variations in this number
are analogous to changing the vertical offset of the waveform.
The
WFMInpre
:YMUlt
, WFMIn pre:YOFf, and WFMIn pre:YZEro commands
are used to convert waveform record values to units specified using the
2-958 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
