Compliance Info
rmation
Pollution Degree
Pollution Degree 2 (as defined in IEC 61010-1). Note: Rated for indoor use only.
Installation (Overvoltage) Category Descriptions
Terminals on this product m ay have different installation (overvoltage) category designations. The installation categories are:
Measurement Category IV. For m easurements performed at the source of low-voltage installation.
Measurement Category III. For measurements performed in the building installation.
Measurement Category II. For measurements performed on circuits directly connected to the low-voltage installation.
Measurement Category I. For measurements performed on circuits not directly connected to MAINS.
Overvolta
ge Category
Mains: Overvoltage Category II
Measurement inputs:
MSO5000, DPO5000, and DPO7000 instruments in 50 Ohm mode and MSO70000/C, DSA70000B/C, and DPO70000B/C
instruments are CAT 1 with no impulse allowed.
DPO7000 instruments are CAT 1 in 1 Meg-Ohm mode.
MSO5000 and DPO5000 instruments are CAT II in 1 Meg-Ohm mode.
(As defined in IEC 61010-1)
x MSO70000/C, DPO/DSA70000B /C, D PO7000, and MSO /DP O5000 Series User Manual
