Display a Wavefo
rm
Display a Wave
form
This section contains concepts and procedures for displaying a waveform. Detailed information is available in the online help.
Setting the Display Style
To set the display style select Display >
Display Style, and then select one of the
following styles:
Displays waveforms with
lines drawn between
record points.
Displays waveform
record points as dots on
the screen.
Displays the actual
samples. Interpolated
points a
re not displayed.
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DP O5000 Series U ser M anual 89
