Tektronix MSO70000 Series

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performanc e test Minimum Incoming Outgo ing Maximum
Ch1 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+1.49V
+ 1.849 V
+1.49V
__________
__________
__________
__________
__________
__________
+1.55V
+1.55V
+1.55V
Ch1 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position s etting, 0 V offset
+5 Div position s etting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+3.876V
+3.876V
+3.876V
Ch2 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
__________
__________
__________
__________
__________
__________
+77.52mV
+77.52mV
+77.52mV
Ch2 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
__________
__________
__________
__________
__________
__________
+155.04mV
+155.04mV
+155.04mV
Ch2 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
__________
__________
__________
__________
__________
__________
+387.60mV
+387.60mV
+387.60mV
Ch2 100 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
__________
__________
__________
__________
__________
__________
+775.20mV
+775.20mV
+775.20mV
Ch2 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+1.49V
+1.49V
+1.49V
__________
__________
__________
__________
__________
__________
+1.55V
+1.55V
+1.55V
Ch2 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position s etting, 0 V offset
+5 Div position s etting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+3.876V
+3.876V
+3.876V
Ch3 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
__________
__________
__________
__________
__________
__________
+77.52mV
+77.52mV
+77.52mV
Ch3 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
__________
__________
__________
__________
__________
__________
+155.04mV
+155.04mV
+155.04mV
Ch3 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
__________
__________
__________
__________
__________
__________
+387.60mV
+387.60mV
+387.60mV
3–30 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
