Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test Minimum Incoming Outgoing Maximum
Ch3 200 mV Vert scale s etting,
-5 Div position setting, +1.25 V offset
5 Div position setting, -1.25 V offset
+ 1.965 V
- 2.035 V
__________
__________
__________
__________
+ 2.035 V
- 1.965 V
Ch3 500 mV Vert scale s etting,
-5 Div position setting, 0 V offset
5 D iv position setting, 0 V offset
+ 2.434 V
- 2.566 V
__________
__________
__________
__________
+ 2.566 V
- 2.434 V
Ch4 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
5 Div position setting, -0.45 V offset
+ 495.75 mV
- 504.25 mV
__________
__________
__________
__________
+ 504.25 mV
- 495.75 mV
Ch4 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
5 Div position setting, -0.4 V offset
+ 494.75 mV
- 505.25 mV
__________
__________
__________
__________
+ 505.25 mV
- 494.75 mV
Ch4 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
5 Div position setting, -0.25 V offset
+ 491.75 mV
- 508.25 mV
__________
__________
__________
__________
+ 508.25 mV
- 491.75 mV
Ch4 100 mV Vert scale s etting,
-5 Div position setting, +2.0 V offset
5 Div position setting, -2.0 V offset
+ 2.474 V
- 2.526 V
__________
__________
__________
__________
+ 2.526 V
- 2.474 V
Ch4 200 mV Vert scale s etting,
-5 Div position setting, +1.25 V offset
5 Div position setting, -1.25 V offset
+ 1.965 V
- 2.035 V
__________
__________
__________
__________
+ 2.035 V
- 1.965 V
Ch4 500 mV Vert scale s etting,
-5 Div position setting, 0 V offset
5 D iv position setting, 0 V offset
+ 2.434 V
- 2.566 V
__________
__________
__________
__________
+ 2.566 V
- 2.434 V
