Tektronix MSO70000 Series

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test Minimum Incoming Outgoing Maximum
MSO71604C and DPO71604C, 16 GHz
10 mV, rms
N/A
__________ __________
1.219 ps
10 mV, pk-pk
N/A
__________ __________
12.19 ps
50 mV, rms
N/A
__________ __________
1.154 ps
50 mV, pk-pk
N/A
__________ __________
11.54 ps
100 mV, rms
N/A
__________ __________
1.159 ps
100 mV, pk-pk
N/A
__________ __________
11.59 ps
MSO71254C and DPO71254C, 12.5 GHz
10 mV, rms
N/A
__________ __________
1.333 ps
10 mV, pk-pk
N/A
__________ __________
13.33 ps
50 mV, rms
N/A
__________ __________
1.212 ps
50 mV, pk-pk
N/A
__________ __________
12.12 ps
100 mV, rms
N/A
__________ __________
1.228 ps
100 mV, pk-pk
N/A
__________ __________
12.28 ps
MSO70804 and DSA/DPO70804B, 8 GHz
10 mV, rms
N/A
__________ __________
1.354 ps
10 mV, pk-pk
N/A
__________ __________
13.54 ps
50 mV, rms
N/A
__________ __________
1.235 ps
50 mV, pk-pk
N/A
__________ __________
12.35 ps
100 mV, rms
N/A
__________ __________
1.241 ps
100 mV, pk-pk
N/A
__________ __________
12.41 ps
MSO70604 and DPO70604B, 6 GHz
10 mV, rms
N/A
__________ __________
1.445 ps
10 mV, pk-pk
N/A
__________ __________
14.45 ps
50 mV, rms
N/A
__________ __________
1.295 ps
50 mV, pk-pk
N/A
__________ __________
12.95 ps
100 mV, rms
N/A
__________ __________
1.329 ps
100 mV, pk-pk
N/A
__________ __________
13.29 ps
MSO70404 and DPO70404B, 4 GHz
10 mV, rms
N/A
__________ __________
1.674 ps
10 mV, pk-pk
N/A
__________ __________
16.74 ps
50 mV, rms
N/A
__________ __________
1.437 ps
50 mV, pk-pk
N/A
__________ __________
14.37 ps
100 mV, rms
N/A
__________ __________
1.478 ps
100 mV, pk-pk
N/A
__________ __________
14.78 ps
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–39
