Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
Characteri
stic
Descriptio
n
Sensitivit
y range
≥ 4 GHz mode
ls, 50 Ω
100 mV/Ful
l Scale to 5 V/Full Scale. Below 100 mV/Full Scale, Full Scale (FS) is software zoom.
<4GHzmod
els, 50 Ω
1 mV/div t
o 1 V/division, in a 1-2-5 sequence
Fine adjustment available with ≥1% resolution
< 4 GHz models, 1 MΩ 1 mV/div to 10 V/division, in a 1-2-5 sequence
Fine adjustment available with ≥1% resolution
DC gain accuracy, sample or
average acquisition mode,
≥ 4 GHz models
±2%
DC gain accuracy, sample or
average acquisition mode,
< 4 GHz models
± 1.0% with 0 V net offset
Add 0.5% for ranges <2 mV/div
Add 1.5% x | net offset/Max offset | for ranges <5 mV/div
Add 0.5% x | net offset/Max offset | for ranges ≥ 5 mV/div
Add 0.5% for ranges ≥ 1V/divin1MΩ coupling and with net offset >10 V
DC vol
tage measurement
accuracy, ≥ 4 GHz models
Gain setting DC measurement accuracy
100 mV/FS to 995 mV/FS ±[2% | reading - net offset | + 0.35% | net offset | +1.5 mV
+ 0.014 FS]
Avera
ge acquisition mode
( ≥16 averages)
1 V/FS to 5 V/FS ±[2% | reading - net offset | + 0.35% | net offset | +7.5 mV
+0.0
14 FS]
Delta voltage measurement
bet
ween any two averages
of ≥16 waveforms acquired
under the same setup and
amb
ient conditions
100
mV/FS to 5 V/FS
±[2
% | reading | + 0.008 FS]
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–3
