Tektronix MSO70000 Series Technical Reference

Performance Verification (MSO/DPO5000 Series)
DC Gain Accuracy
Performance
checks Bandwidth Vertical scale Low limit Test result High limit
1 mV/div -2.0% 2.0%
2 mV/div -1.5% 1.5%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
50 mV/div -1.5% 1.5%
100 m V /div -1.5% 1.5%
200 m V /div -1.5% 1.5%
500 m V /div -1.5% 1.5%
Channel 2 DC
Gain Accurac
y,
0 V offset, 0 V
vertical position,
50 Ω
20 MHz
1 V/div -1.5% 1.5%
1 mV/div -2.0% 2.0%
2 mV/div -1.5% 1.5%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
50 mV/div -1.5% 1.5%
63.5 m V/div -3.0% 3.0%
100 m V /div -1.5% 1.5%
200 m V /div -1.5% 1.5%
500 m V /div -1.5% 1.5%
20 MHz
1 V/div -1.5% 1.5%
250 MHz
20 mV/div -1.5% 1.5%
Channel 2 DC
Gain A
ccuracy,
0 V offset, 0 V
vertical position,
1MΩ
FULL
20 mV/div -1.5% 1.5%
4–8 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
