Performance Verification (MSO/DPO5000 Series)
DC Offset Accuracy
Performance
checks Vertical scal
e
Ve rtical offs
et
1
Low limit Test result
High limit
All models:
1 mV/div
900 mV 895.3 mV 904.7 mV
1 mV/div
-900 mV -904.7 m V -895.3 mV
100 mV/div
5.0 V 4.965 V 5.035 V
Channel1DC Offset
Accuracy,
20 MHz BW, 50 Ω
100 mV/div
-5.0 V -5.035 V -4.965 V
1 mV/div
900 mV 895.3 mV 904.7 mV
1 mV/div
-900 mV -904.7 m V -895.3 mV
100 mV/div
9.0 V 8.935 V 9.065 V
100 mV/div
- 9.0V -9.065 V -8.935 V
500 mV/div
9.0 V 8.855 V 9.145 V
500 mV/div
- 9.0V -9.145 V -8.855 V
1.01 V/div
99.5 V 98.80 V 100.2 V
1.01 V/div
-99.5 V -100.2 V -98.80 V
3V/div
99.5 V 98.4 V 100.6 V
Channel1DC Offset
Accuracy,
20 MHz BW, 1 MΩ
3V/div
-99.5 V -100.6 V -98.4 V
1 mV/div
900 mV 895.3 mV 904.7 mV
1 mV/div
-900 mV -904.7 m V -895.3 mV
100 mV/div
5.0 V 4.965 V 5.035 V
Channel 2 DC
Offset Ac
curacy,
20 MHz BW, 50 Ω
100 mV/div
-5.0 V -5.035 V -4.965 V
1 mV/div
900 mV 895.3 mV 904.7 mV
1 mV/div
-900 mV -904.7 m V -895.3 mV
100 mV/div
9.0 V 8.935 V 9.065 V
100 mV/div
-9.0 V -9.065 V -8.935 V
500 mV/div
9.0 V 8.855 V 9.145 V
500 mV/div
- 9.0V -9.145 V -8.855 V
1.01 V/div
99.5 V 98.80 V 100.2 V
1.01 V/div
-99.5 V -100.2 V -98.80 V
3V/div
99.5 V 98.40 V 100.6 V
Channel2DC Offset
Accurac
y,
20 MHz BW, 1 MΩ
3V/div
-99.5 V -100.6 V -98.4 V
