Tektronix MSO70000 Series Technical Reference

Performance Verification (MSO/DPO5000 Series)
Random Noise, Sample Acquisition Mode
Ve rtical sensitivity = 100 mV/div
Performance checks 1 MΩ 50 Ω
Bandwidth Test result (mV) High limit (m V) Test result (mV) High limit (mV)
MSO5034, DPO5034, MSO5054, DPO5054
Full 8.13 8.13
250 MHz limit 6.10 6.10
Channel 1
20 MHz limit 4.10 4.10
Full 8.13 8.13
250 MHz limit 6.10 6.10
Channel 2
20 MHz limit 4.10 4.10
Full 8.13 8.13
250 MHz limit 6.10 6.10
Channel 3
20 MHz limit 4.10 4.10
Full 8.13 8.13
250 MHz limit 6.10 6.10
Channel 4
20 MHz limit 4.10 4.10
Sample Rate and Delay Time Accuracy
Performance checks Low limit Test result High limit
-1 di
visions
+1 di
visions
4–18 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
