Tektronix MSO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
20 GS/s
Analog bandwidth setting
Input
Frequency
2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bits 6.3 bits 6.5 bits 6.6 bits
510 M Hz 5.9 bits 6.3 bits
1010 MHz 5.6 bits
1510 MHz 5.6 bits
2010 MHz 5.2 bits
2510 MHz 4.5 bits
10 GS/s
Analog bandwidth setting
Input
Frequency
2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bi
ts
6.3 bi
ts
6.5 bi
ts
6.6 bi
ts
510 M Hz 5.9 bits 6.3 bits
1010 MHz 5.6 bits
1510
MHz
5.7 b
its
2010 MHz 5.8 bits
2510 MHz 5.5 bits
DPO7104
En
hanced bandwidth
20
GS/s
Analog bandwidth setting
Input
Frequency
1.0 GHz 0.5 GHz
10 MHz 6.7 bits 7.2 bits
510 M Hz 6.7 bits 7.2 bits
1010 MHz 6.7 bits
10 GS/s
Analog bandwidth setting
Input
Frequency
1.0 GHz 0.5 GHz
10 MHz 6.6 bits 7.1 bits
510 M Hz 6.5 bits 7.1 bits
1010 MHz 6.5 bits
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–19
